TB Wood’s 8S 3/4 Sure-Flex Sleeve Coupling Flange
TB Wood’s 8S 3/4 Sure-Flex Sleeve Coupling Flange, 3/4 inch bore.
Apple Shopping Event
Hurry and get discounts on all Apple devices up to 20%
Sale_coupon_15
$40.50
1 in stock
1 in stock
20
People watching this product now!
Payment Methods:
TB Wood’s 8S 3/4 Sure-Flex Sleeve Coupling Flange.
Specifications
- Brand: TB Wood’s
- Part number: 8S 3/4
- Type: Flexible Coupling Flange
- Coupling Size: Size 8
- Bore Diameter: 3/4 inch (Plain / Finished Bore)
- Outside Diameter: 5 29/64 inches
- Hub Diameter: 3 1/4 inches
- Length Through Bore: 2 3/32 inches
- Maximum Speed: 4,500 RPM
- Torque Capacity: Rated for 1,475 in-lb of continuous torque when paired with standard EPDM or Neoprene sleeves
- Material: High-strength cast iron
- Condition: New
- Country of origin: Mexico
Typical applications
Replacement drive and bearing part for HVAC and industrial equipment. Match the part number, bore size and dimensions of the original before ordering.
Before you order, match the part number or the specs on the nameplate of the part you are replacing. Not sure it fits? Send us the model and serial number of your unit and we will confirm.
| mpn |
8S 3/4 |
|---|
